The star fuel
Hydrogen is the lightest known element.
Hydrogen is also the most abundant element in the universe. In fact, a whopping 90% of the universe’s atoms are hydrogen. Most of the stars are fueled by hydrogen via nuclear fusion.
If you are interested in learning about the role of hydrogen in the universe’s formation, I highly recommend this article by astrophysicist Ethan Siegel.
Hydrogen has a central role in our human biology as well. Two-thirds of the atoms in our bodies are hydrogen. And it plays literally a vital role. For example, both water, which makes up 60% of our body mass, and DNA comprise hydrogen.
Hydrogen typically bonds with another hydrogen atom or other elements like oxygen and nitrogen. Hydrogen bonds with other atoms, as it is the most energetically favorable way of existing. More on chemical bonds here.
The current use cases of hydrogen
We, humans, have learned to use this wonder element, hydrogen also in our society.
In 2020, we used 90 Mt (megatons) of hydrogen. Most of this hydrogen was used in oil refining and chemical production.
In oil refining, hydrogen is used to remove impurities like sulfur from the oil and make heavy oil fractions into lighter ones.
In chemical production, hydrogen is used to make ammonia and methanol. Ammonia is an important ingredient for nitrogen fertilizers that feed the world. Methanol, on the other hand, is widely used to make plastics, paints, and pharmaceuticals.
A tiny fraction of hydrogen is also used in iron and steel production in an alternative low-carbon process called the Direct Reduced Iron.
The future use cases of hydrogen
If you have been following the news, you must have noticed that there is a lot of hype around hydrogen.
The US recently launched an $8 billion program for developing clean hydrogen hubs across the country. The European Union and some of its biggest member countries, like Germany and France, have had hydrogen as part of their energy strategies for several years (the hydrogen strategies of the EU, Germany, and France).
Several countries are proponents of hydrogen, as it can help reach their zero-carbon goals.
The Hydrogen Council expects the demand for hydrogen to grow from 90 Mt in 2020 to 660 Mt in 2050. That’s over 600% growth in just 30 years!
The growth in hydrogen demand is fueled (pun intended) by the following use cases:
Mobility
New industry feedstock (e.g. steel production)
Power generation
Building and industry heat
1. Mobility
Hydrogen is expected to play an important role in decarbonizing transportation, where batteries can’t do the work. This generally means transportation, which involves high power requirements like trucking, shipping, and aviation.
Hydrogen can be used directly in a fuel cell or combusted.
Alternatively, hydrogen can be converted into hydrogen-based fuels. Most synthetic fuel conversion mechanisms require hydrogen as feedstock. For example, the most common synthetic fuel production process, Fischer-Tropsch, can convert atmospheric/waste CO2 and green hydrogen into fuels like gasoline, diesel, and jet fuel.
Read more about hydrogen’s role as aviation fuel in the Survivaltech.club’s deep dive on aviation.
2. New industry feedstock (e.g. steel production)
Hydrogen can be used to decarbonize steel production, which accounts for 8% of the global CO2 emissions. Hydrogen can be used either in the Direct Reduced Iron (DRI) or the hydrogen-plasma process.
To learn more about the topic, I highly recommend watching this super informative video by Max Planck Institute for Iron Research.
3. Power generation
In the power sector, the main use case for hydrogen would be the seasonal balancing of the electricity grid.
The more intermittent renewables like solar and wind are connected to the electricity grid, the more need there is to balance the grid to meet the electricity demand with supply. Not only does solar and wind production vary with the time of the day, but it also varies with the season.
4. Building and industry heat
Hydrogen seems to have limited use in heating buildings due to cost-efficient alternatives (e.g., heat pumps).
However, hydrogen could play a significant role in decarbonizing industries that require high temperatures in their processes, like cement production, glass making, and aluminum melting.
Hydrogen production
Hydrogen sounds like a great solution for many challenges! Doesn’t it? But there’s a catch.
Hydrogen is produced from a variety of resources including fossil fuels…
Hydrogen types (based on their production method)
Green hydrogen (renewable energy)
Blue hydrogen (fossil fuels with carbon capture, utilization, and storage (CCUS))
Grey hydrogen (fossil fuels)
1. Green hydrogen (renewable energy)
Green hydrogen is produced by splitting water into hydrogen and oxygen with renewable electricity. This process of splitting water is called water electrolysis.
No CO2 is created as a by-product of water electrolysis. More about the electrolysis process and green hydrogen in general in the upcoming Part 2 of this hydrogen deep dive series!
2. Blue hydrogen (fossil fuels with CCUS)
Blue hydrogen is made from fossil fuels like natural gas (methane) and coal. Hydrogen is also created as a by-product of oil refining.
The process that makes hydrogen from natural gas is called steam methane reforming. On the other hand, the process that makes hydrogen from coal is called coal gasification.
Both of these processes (steam methane reforming and coal gasification) produce CO2.
Blue hydrogen plants are equipped with CCUS units that capture some of the CO2 emissions. Some CO2 is still released into the atmosphere. Furthermore, hydrogen is mostly produced from methane, which easily leaks into the atmosphere and causes strong climate warming (fugitive methane emissions).
3. Grey hydrogen (fossil fuels)
Likewise to blue hydrogen, grey hydrogen is produced from natural gas and coal and as a by-product of oil refining.
No CO2 is captured at the end of the process. Methane leakages also contribute to the greenhouse gas emissions of grey hydrogen.
The state of hydrogen production today
Today, almost all hydrogen is grey hydrogen. Hydrogen production was responsible for 900 Mt of CO2 emissions in 2020. That’s as much as the annual CO2 emissions of the UK and Indonesia combined.
Only 0.03% (30 kt) of the hydrogen was produced from renewable sources (green hydrogen) and 0.7% (0.7 Mt) of the fossil-fuel produced hydrogen had CCUS in place (blue hydrogen) in 2020 (IEA, 2021).
A huge ramp-up of hydrogen production has to happen to be able to consider hydrogen as a clean fuel.
Hydrogen and methane leakages
When making this ramp-up of annual hydrogen production to 660Mt by 2050, special attention has to be paid to the way of doing this.
Firstly, green hydrogen is the way to go.
Blue hydrogen seems like a great idea due to lower deployment costs and faster ramp-up until you look at its carbon footprint.
A study by Howarth and Jacobson found that blue hydrogen produces only 9-12% fewer emissions than grey hydrogen in terms of CO2-equivalent over a 20-year time frame assuming a 3.5% methane leakage rate and 85% CO2 capture rate.
Blue hydrogen is primarily produced from natural gas (methane). Methane leaks easily into the atmosphere causing a strong warming effect. (Read more about methane in Survivaltech.club’s deep dive)
Secondly, hydrogen leakage has to be minimized.
Hydrogen is an indirect greenhouse gas.
When hydrogen leaks into the atmosphere, it extends the lifetime of methane via a series of chemical reactions. It also leads to the formation of ozone in the troposphere and water vapor in the stratosphere. Both ozone and water vapor are greenhouse gases.
To learn more about these chemical reactions, check out this preprint of a scientific article or this recent article by the Environmental Defense Fund.
Now it’s the time to make sure that we will make hydrogen a climate solution, not another challenge.
In Part 2 of this deep dive series, we’ll take a look specifically at green hydrogen!
If you liked this article, please share it with your climate friends!🌍
Best, Pauliina💚
Sources
Derwent, R. G., Stevenson, D. S., Utembe, S. R., Jenkin, M. E., Khan, A. H., and Shallcross, D. E. (2020) Global modelling studies of hydrogen and its isotopomers using STOCHEM-CRI: Likely radiative forcing consequences of a future hydrogen economy. International Journal of Hydrogen Energy, 45(15), pp. 9211-9221, Link.
Grochala, W. (2015) First there was hydrogen. Nature Chemistry, 7, 264. Link.
Howarth, R. W. & Jacobson, M. Z. (2021). How green is blue hydrogen? Energy Science and Engineering, 9(10), pp.1676-1687. Link.
Hydrogen Council and McKinsey & Company (2021). Hydrogen for Net-Zero. Link.
IEA (2021). Global Hydrogen Review 2021. Link.
McKinsey & Company (2022). Decarbonization challenge for steel. Link.
Menon, S. (2022). Everyone’s excited about this climate solution, but it could create a new climate problem. We need to talk about hydrogen. EDF. Link.
Ocko, I. B. & Hamburg, S. P. (2022). Climate consequences of hydrogen leakage. Atmospheric Chemistry and Physics. Preprint. Link.
